Home / All / 4500RPM DIFFUL&WELLUP SOLAR SUBMERSIBLE PUMP / DIFFUL&WELLUP DC SUBMERSIBLE PUMP / 4"DC BRUSHLESS SOLAR PUMP WITH S/S IMPELLER | 4500 RPM SOLAR PUMP| DC Hot-sale pump for household water supply
4"DC BRUSHLESS SOLAR PUMP WITH S/S IMPELLER | 4500 RPM SOLAR PUMP| DC Hot-sale pump for household water supply
| Categories | DIFFUL&WELLUP DC SUBMERSIBLE PUMP |
|---|---|
| Trademark/Brand | DIFFUL |
| Model | 4HJSC |
| Material | Stainless Steel |
| Type | Brushless Solar Pump |
| Warranty | 4HJSC-2 year;4HJSC -IN 1-year |
| MOQ | 1set |
| Certificate | CE, ISO9001 |
| Update Time | Oct 30,2025 |
Detail Information
4"DC BRUSHLESS SOLAR PUMP WITH S/S IMPELLER
4"DC brushless solar pump with S/S impeller - stainless impeller, MPPT controller, brushless motor.
Good for farm livestock ,off-grid household water supply and agricultural irrigation.
3"AC/DC &WIDE VOLTAGE BRUSHLESS SOLAR PUMP WITH S/S IMPELLER TECHNICAL DATA
| ITEM | Built-in Controller Model | Voltage | Optimum input voltage(DC) | Power | Max.Flow | Max. Head | Outlet | Cable | Open circuit voltage(VOC) | VOC(-IN Model) |
| 4HJSC3.5-50-48-400 | -IN | 48V | 60V-90V | 400W | 3.5m³/h | 50m | 1.25" | 2m | <120V | <105V |
4HJSC3.5-86-48-600 | 48 | 60V-90V | 600W | 3.5m³/h | 86m | 1.25" | 2m | <120V | <105V | |
4HJSC3.5-86-72-600 | 72V | 90V-120V | 600W | 3.5m³/h | 86m | 1.25" | 2m | <170V | <155V | |
4HJSC3.5-105-48-750 | 48 | 60V-90V | 750W | 3.5m³/h | 105m | 1.25" | 2m | <120V | <105V | |
4HJSC3.5-105-72-750 | 72 | 90V-120V | 750W | 3.5m³/h | 105m | 1.25" | 2m | <170V | <155V | |
4HJSC3.5-140-72-1100 | 72 | 90V-120V | 1100W | 3.5m³/h | 140m | 1.25" | 2m | <170V | <155V | |
4HJSC3.5-140-110-1100 | 110 | 110V-150V | 1100W | 3.5m³/h | 140m | 1.25" | 2m | <220V | <205V | |
4HJSC4.8-203-110-1500 | 110 | 110V-150V | 1500W | 4.8m³/h | 203m | 1.25" | 2m | <220V | <205V | |
4HJSC6-45-48-500 | 48 | 60V-90V | 500W | 6m³/h | 45m | 1.25" | 2m | <120V | <105V | |
| 4HJSC6-67-48-750 | 48 | 60V-90V | 750W | 6m³/h | 67m | 1.25" | 2m | <120V | <105V | |
| 4HJSC6-67-72-750 | 72 | 90V-120V | 750W | 6m³/h | 67m | 1.25" | 2m | <170V | <155V | |
4HJSC6-101-72-1100 | 72 | 90V-120V | 1100W | 6m³/h | 101m | 1.25" | 2m | <170V | <155V | |
4HJSC6-101-110-1100 | 110 | 110V-150V | 1100W | 6m³/h | 101m | 1.25" | 2m | <220V | <205V | |
4HJSC6-146-110-1300 | 110 | 110V-150V | 1300W | 6m³/h | 146m | 1.25" | 2m | <220V | <205V | |
4HJSC9.5-50-72-750 | 72V | 90V-120V | 750W | 9.5m³/h | 50m | 2" | 2m | <170V | <155V | |
4HJSC9.5-50-110-750 | 110V | 110V-150V | 750W | 9.5m³/h | 50m | 2" | 2m | <220V | <205V | |
4HJSC9.5-75-110-1100 | 110V | 110V-150V | 1100W | 9.5m³/h | 75m | 2" | 2m | <220V | <205V | |
4HJSC9.5-90-110-1500 | 110V | 110V-150V | 1500W | 9.5m³/h | 90m | 2" | 2m | <220V | <205V | |
4HJSC15-45-72-750 | 72V | 90V-120V | 750W | 15m³/h | 45m | 2" | 2m | <170V | <155V | |
4HJSC15-45-110-750 | 110V | 110V-150V | 750W | 15m³/h | 45m | 2" | 2m | <220V | <205V | |
4HJSC15-55-110-1100 | 110V | 110V-150V | 1100W | 15m³/h | 55m | 2" | 2m | <220V | <205V | |
4HJSC16-70-110-1500 | 110V | 110V-150V | 1500W | 16m³/h | 70m | 2" | 2m | <220V | <205V | |
4HJSC2048-110-1500 | 110V | 110V-150V | 1500W | 20m³/h | 48m | 2" | 2m | <220V | <205V | |
4HJSC25-26-110-1500 | 110V | 110V-150V | 1500W | 25m³/h | 26m | 2" | 2m | <220V | <205V |
4"DC BRUSHLESS SOLAR PUMP WITH S/S IMPELLER Performance Curve
HOW TO CHOOSE A PUMP
Confirm you technical requirement
How deep is your well(bore hole)?
How far is the distance between tank and well?
What's you requirement about the flow(L/H)?
Compare your requirement with our product
Calculate "Actual Pump Head" and find the proper pump with the right head.
Then you can choose the pump you want according to different flow and prices.
