Use solar power to pump groundwater. Provides a cost-effective way to supply users with safe and clean water.
Your preferred irrigation system. Automated systems reduce operating costs while increasing crop yields.
Using a solar pool pump makes a lot of sense, and pools tend to get more use when the sun is shining.
Submerging depth can reach 150 metersMore energy saving and environmental protection with water-filled motor
The whole pump is small volume, saving the pump installation cost into the well.Maximum 6000RPM.
Reduce reliance on the grid, reduce carbon emissions and reduce operating costs to ensure your production is on target.
MPPT technology maximizes the power utilization of photovoltaic modules and continues to improve.
Water-filled motors ensure reliability and avoid oil contamination. Brushless DC motor is specially designed for solar power.
There is nothing more important than drinking water, and choosing a safe and reliable water supply is crucial. DIFFUL solar water pump system delivers drinking water and domestic water to more than 100,000 families and communities around the world every year.
For long-term use and maintenance costs, a solar water pumping system is much less expensive than using a grid connection or using diesel power.
Serving Families Water problem is the most important issue for every family. Pumping groundwater is the best way to provide people with safe and clean drinking water. It is most economical to use solar energy systems to provide drinking water.
Serving Larger Communities DIFFUL solar water pumps have solved water problems for communities of up to 100,000 people. Water storage, hybrid solutions are used simultaneously to reliably supply water to the community 24 hours a day, to meet community water needs in a more cost-effective manner.
Water Companies Water utilities can reduce operating costs by converting diesel pumps to solar-powered pumping systems. DIFFUL solar water pumping system provides a more economical solution for water abstraction and pressure boosting applications.
Calculate the "actual lift needed" and find an appropriate pump.
Then choose the most suitable pump according to different flow rates and prices as well as pump materials.
Lift underwater (the vertical distance between the water pump and the water surface)
Lift above water (the vertical distance between water surface and the wellhead)
The horizontal distance between the well and the water tank
Tank height
The power of the solar photovoltaic panel array is recommended to be 1.3 times or more than the power of the water pump.The voltage of the solar photovoltaic panel array needs to meet the voltage range of the water pump.
3 Inch Plastic Impeller Solar Submersible Pump
Model: 3DPC3.5-95-72-750
Requirements for solar photovoltaic panel array: power ≥ 750w*1.3 (that is, power ≥ 975w)
Solar panel:
3 solar panels in series:
In this case, the power and voltage requirements of the pump can be satisfied, so this solar photovoltaic panel array scheme is acceptable.
The battery is not necessary, if you need to use it at night or in rainy weather, you can choose Difful AC/DC hybrid solar submersible pump.
If you need to use a battery, a charge manager must be connected. The voltage after the battery is connected needs to meet the voltage of the water pump. The connection method of charging manager is shown in the figure.
The water pump comes with a cable of 2 meters. The length can be customized according to your actual needs. Customers can also extend the cable themselves.
If the required cable is more than 200m, it is recommended to chooseDifful solar submersible pump with built-in controller.
By utilizing stored water, a solar submersible pump system can reliably supply water 24 hours a day without the need for expensive batteries, grid connections or generators.
Hybrid solutions can be deployed where solar and generator/grid are both available to meet all needs in a more cost-effective manner.
Solve the problems of insufficient water pressure and small water output for families, communities and villages.
We are famous for our professional services and solutions. Please contact us to let us know what you need and what problems you want to solve. We will provide the best solutions for your needs.
